Product Description
ICEMEDAL use a flake ice machine and an ice rake system for
concrete cooling in fishery or large infrastructure projects. Flake
ice is perfect to preserve aquatic goods, and we can make it
seawater types. Due to the good cooling performance of the flake
ice machine, we solved the problem of hydration heat in the
concrete forming process. We are a reliable partner that can help
you ensure the quality of your business.
Product Parameters
| Model | Daily Output (T/24h) | Cooling method | Compressor Power | Fan Power for Cooling Tower | Cooling Pump Power | Unit Size (L*W*H mm) | Unit N.W. (KG) |
| BF 500 | 0.5 | Air | 4.1 kw | -- | -- | 1280*800*800 | 160 |
| BF 1000 | 1 | Air | 7.44 kw | -- | -- | 1320*900*900 | 210 |
| BF 2000 | 2 | Air | 10 kw | -- | -- | 1750*1100*1050 | 360 |
| BF 3000 | 3 | Water | 8.45 kw | 0.37 kw | 1.5 kw | 1500**1250*1260 | 1000 |
| BF 5000 | 5 | Water | 13.49 kw | 0.75 kw | 2.2 kw | 1900*1500*1470 | 1100 |
| BF 6000 | 6 | Water | 19.94 kw | 0.75 kw | 2.2 kw | 1900*1500*1470 | 1100 |
| BF 8000 | 8 | Water | 24.2 kw | 1.5 kw | 2.2 kw | 2400*1900*1860 | 1300 |
| BF 10000 | 10 | Water | 33.8 kw | 1.5 kw | 4 kw | 2500*2000*1860 | 1500 |
| BF 15000 | 15 | Water | 44.5 kw | 1.5 kw | 4 kw | 3350*2150*1960 | 3200 |
| BF 20000 | 20 | Water | 64 kw | 1.5 kw | 5.5 kw | 3400*2220*2230 | 4200 |
| BF 25000 | 25 | Water | 76.5 kw | 2.2 kw | 5.5 kw | 3700*2250*2510 | 4600 |
| BF 30000 | 30 | Water | 93.7 kw | 2.2 kw | 7.5 kw | 4700*2250*2520 | 5000 |
| BF 40000 | 40 | Water | 118 kw | 2.2 kw | 7.5 kw | 5000*2300*2700 | 7500 |
* Compressor brand: Bizter / Hanbell; Refrigerant: R22/R404R.
* Power supply: voltage 380 V/3P/50Hz (For non-standard voltage,
unit configuration needs to be calculated separately)
* Operating conditions: T (water supply):20℃, T (ambient): 32℃, T
(condensing): 38℃, T (evaporating): -20℃.
* Note: The actual ice production varies due to the influence of
water supply temperature and ambient temperature.
* The final interpretation of the above mentioned parameters is in
Icemedal, there will be no further notice, if there is any
technical change.
Product Advantages
1.Spiral ice skate blade design does not damage the blade.
2.Continuous butt welding and spraying ensures that the evaporator
is not easy to deform and reduces the mechanical resistance during
the operation of the ice maker
3.Smooth circulation, low resistance, improve refrigeration effect
and reduce energy consumption
4.The ice has uniform thickness, large coverage area and no dry
adhesion
5.Daily Capacity: 5-20 ton 24 hours.
6.Machine power supply: 3 phase industrial power supply.
7.Control system is using Siemens PLC and touch screen, it is very
easy to use. Meanwhile, it can protect the machine when there are
water shortage, ice full, high/low pressure alarm, and motor
reversal.
8.Evaporator and ice cutter are made of high quality material, the
lifespan is ensured.
9.We provide the seawater type ice machine, which is able to use
seawater to make ice.
10.Auto flake ice system available by using ice storage with rake.
11.Flake ice is dry, the edge of ice is not sharp, it is good for
direct cooling of food.
Product Application
Flake Ice Dry, pure, powder-less, not easy to block, its thickness
is about 1.5mm~2.2mm, without edges or corners which will can
product the cooling food, fish, seafood and other products. Flake
ice machine and an ice rake system also for concrete cooling in
fishery or large infrastructure projects.
Our Project
Packaging
1. Standard wooden case.
2. Completely ice machine we offer that include ice machine,
cooling tower, water pump, water pipes and water pipe fittings.
3.Customer only need prepare power for the machine, so machine can
run.
4. All required components for install the machine will be
provided.
Our Company
Certifications
FAQ
| 1.Q: I want to build an ice factory. How big the equipment is? |
A:This needs to consider the model according to the output of ice
you need in a day. The volume and ice ouput of different models are
different. Refer to the parameter table on the details page.
|
| 2.Q: Where is the best place to install the equipment and what
other factors need to be considered? |
A:There is no direct sunlight and good ventilation. It is also
necessary to consider whether there is water source and stable
power supply. The water pipe needs to be large enough and have
enough power.
|
| 3.Q: How to transport and install equipment? |
| A:After the goods arrive at the port of destination, forklifts need
to be arranged, and the machinery is relatively heavy. |
we will tested and install well the machine before shipment, all
necessary spare parts,operation,manual and CD are provided to guide
the installation. We can send our engineer to assist the
installation and provide technical support and train your workers.
The end-user provide accommodation and round-trip ticket for our
engineer.
|
| 4,Q: What is the price, what is the daily maintenance, and does it
need to be looked after? |
A:The prices of various models are different. Please consult the
salesman for details. Keep the unit clean and sanitary, and clean
the scale of water tank and evaporator from time to time. Check
whether the apron pipe of the apron is blocked. There are still
many details to pay attention to we will provide the operation
manual.
|
| 5,Q: How much water and electricity does a ton of ice need? |
| A:The production cost of flake ice is very economical. It only
takes about 85 degrees of electricity to refrigerate 16 ℃ water
into 1 ton of flake ice. |
