icemedal Automatic High Productivity Cube Ice Maker Machine small Ice Machine Making

Product Description

Specification

3 tons per day large capacity cube ice machine for hotels & restaurants paremeters
Model Parameters			CV 1000	CV 2000	CV 3000	CV 5000	CV 10000	CV 20000
Daily output (T/24 h)			1	2	3	5	10	20
Compressor Power			4.34 kw	7.88 kw	10.58 kw	21 kw	42 kw	73.5 kw
Fan Power of Cooling Tower			0.18 kw	0.37 kw	0.56 kw	0.75 kw	1.5 kw	2.2 kw
Cooling Pump Power			1.1 kw	1.5 kw	1.5 kw	2.2 kw	4 kw	5.5 kw
Unit Size	L (mm)	1800	1630	1980	2890	5730	7100
	W (mm)	1000	1600	1630	1780	1780	2250
	H (mm)	1700	1706	1860	1860	2130	2300
Unit N.W. (kg)			800	1000	1200	1600	3000	5000

1.Compressor brand: Bizter / Frascold; refrigerant: R22/ R404A; Cooling Method: Water Cooling / Air Cooling.

Company Profile

FAQ

1. Installation & commissioning

A. Installed by customers according to the manuals, online instructions and live video conference of ICEMEDAL.

B. Installed by ICEMEDAL engineers.

a. ICEMEDAL would arrange 1~3 engineers based on the projects to the installation sites for the final supervision of all installations and commissioning.

b. Customers need to provide local accommodation and round-trip ticket for our engineers and pay for the commissions.

c. Power, water, installation tools and spare parts need to be ready before ICEMEDAL engineers arrive.

2. Warranty & Technical support

A. 1 year after Bill of Lading date.

B. Any failure occurred within the period due to our responsibility, ICEMEDAL will supply the spare parts for free.

C. ICEMEDAL provide full technical support and training courses after equipment installation and commissioning.

D. Permanent technical support & consultation all life long for the machines.

E. Over 25 engineers for instant after-sale services and more than 15 are available for serving overseas.

365 days ×7 ×24 hours phone / Email assistance
